VTCU 68800 X 34400 Delta – 12470/7200 Wye 15_20_25 MVA
Product ID: 218
VTCU Dual Voltage HV 68.6 X 34.4 kV Delta 12.47/7.2 kV Wye Substation Stepdown Transformer
- Size: 15/20/25/28 MVA
- HV_H: 68800
- HV 2: 34400
- Dual HV: 1
- HV TC Type: off Load
- LV_1_X: 12470
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type:
- See Notes:
- High Voltage Vector: Delta
- Low Voltage Vector: Wye
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Top Cover Mounted
- Low Voltage Bushing: Top Cover Mounted
- HV2 Bushing:
- LV2 Bushing:
- Station Type: VTCU Dual Voltage HV 68.6 X 34.4 kV Delta 12.47/7.2 kV Wye Substation Stepdown Transformer
- Live Dead:
- Feed:
- Type:
- Width:
- Length:
- Height:
- Weight: 83500
- Phase: 3
- HZ: 60
- DOM: 2025
- MFG: Virginia
