Reconditioned Westinghouse Transformer
Product ID: 5661
Reconditioned Westinghouse Substation Transformer, 161 kV Delta Primary, 13.8 kV Wye Secondary, 5 Position off circuit tap switch.
- Size: 10/13.3 MVA
- HV_H: 161000
- HV 2:
- Dual HV:
- HV TC Type: OLTC
- LV_1_X: 13800
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type:
- See Notes: Yes
- High Voltage Vector: Delta
- Low Voltage Vector: Wye
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Top Mounted
- Low Voltage Bushing: Top Mounted
- HV2 Bushing:
- LV2 Bushing:
- Station Type: Substation Stepdown
- Live Dead:
- Feed:
- Type: Oil Filled
- Width: 159
- Length: 159
- Height: 154.5
- Weight: 85700
- Phase: 3
- HZ: 60
- DOM: 2018
- MFG: Westinghouse
