McGraw Edison Load Tap Changing Transformer

Product ID: 5742

McGRAW EDISON 15/20/25 MVA Load Tap Changing Transformer. 115 kV Primary with off load tap changer. Selectable 24.9 or 12.47 kV Secondary with Load Tap Changer. Mineral Oil fille Substation Stepdown Transformer. 55/65 Degree rise. 16.8/22.4/28 MVA rating at 65 Degree C. 1984 Year of Manufacture. Manufactured in Canonsburg, PA

  • Size: 15/20/25 MVA
  • HV_H: 115000
  • HV 2:
  • Dual HV:
  • HV TC Type: Off Load Tap Changer
  • LV_1_X: 24940
  • LV_2_Y: 12470
  • LV2 Type:
  • Dual LV: 1
  • LV TC Type: Load Tap Changer
  • See Notes: Yes
  • High Voltage Vector: Delta
  • Low Voltage Vector: Wye
  • High 2 Voltage Vector:
  • Low 2 Voltage Vector: Wye
  • High Voltage Bushing: Top cover mounted
  • Low Voltage Bushing: Top Cover Mounted
  • HV2 Bushing:
  • LV2 Bushing: Top Cover Mounted
  • Station Type: Substation Stepdown
  • Live Dead:
  • Feed:
  • Type: Mineral Oil Filled
  • Width:
  • Length:
  • Height:
  • Weight:
  • Phase: 3
  • HZ: 60
  • DOM: 1984
  • MFG: McGRAW EDISON
