ABB Substation Stepdown Transformer
Product ID: 204
28.6/ 38.1/47.7 MVA ABB Substation Stepdown Transformer
- Size: 28.6/38.1/47.7 MVA
- HV_H: 115000
- HV 2:
- Dual HV:
- HV TC Type: Off Load
- LV_1_X: 13800
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type:
- See Notes: yes
- High Voltage Vector: Wye
- Low Voltage Vector: Delta
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Top Cover Mounted
- Low Voltage Bushing: Top Cover Mounted
- HV2 Bushing:
- LV2 Bushing:
- Station Type: Substation Stepdown
- Live Dead:
- Feed:
- Type: Mineral Oil Filled
- Width:
- Length:
- Height:
- Weight: 148565
- Phase: 3
- HZ: 60
- DOM:
- MFG: ABB
