15 MVA ABB Power Transformer
Product ID: 5713
15/20/25 MVA Abb Power Transformer, Substation Step down 115 kV Delta primary, 12.47 kV Wye secondary
- Size: 15/20/25 MVA
- HV_H: 115000
- HV 2:
- Dual HV:
- HV TC Type: Off Load Tap Changer
- LV_1_X: 12470
- LV_2_Y:
- LV2 Type:
- Dual LV:
- LV TC Type:
- See Notes: Yes
- High Voltage Vector: Delta
- Low Voltage Vector: Wye
- High 2 Voltage Vector:
- Low 2 Voltage Vector:
- High Voltage Bushing: Top Cover Mounted
- Low Voltage Bushing: Top Cover Mounted
- HV2 Bushing:
- LV2 Bushing:
- Station Type: Substation Step down
- Live Dead:
- Feed:
- Type: Mineral Oil Filled
- Width:
- Length:
- Height:
- Weight: 111474
- Phase: 3
- HZ: 60
- DOM: 2004
- MFG: ABB
